Product Details


NISSAN 240SX 89-90 KA24 SINGLE CAM (KA24E) MOTOR T3T4 COMPLETE TURBO CHARGER KIT

Applications:

1989 1990 Nissan 240sx S13 SOHC

comes with the following item:

-T3T4 TURBO CHARGER .63ar
-KA24E STAINLESS TOP MOUNT MANIFOLD
-ALUMINUM PRE-BENT INTERCOOLER PIPE, WITH CLAMPS & SILICONE
-30X12X3 INTERCOOLER CORE
-3" STAINLESS TURBO UPPIPE
-3" STAINLESS TURBO DOWNPIPE
-38MM WASTEGATE (7PSI)
-OIL FEEL LINE, OIL RETURN LINE WITH ALL FITTINGS
-TYPE-RS BLOW OFF VALVE

This is one of the best bang for the buck turbo kits out there!
Everything is ready to go!! With stock injectors and ecu we made as much as 235whp. For better results we recommend bigger injectors, an upgraded fuel pump and ecu reflash (upgrade, or piggy back).

Turbo spec:

T3T4 turbo
Intake: 3 inch
Inlet: 2 inch
Compressor trim: .50ar
Compressor Wheel diameter: 50.16 / 76.84
Turbine Wheel diameter: 54.06 / 65.20
Exhaust Trim: .63ar
Turbine flange type : T3 flange
Down pipe flange type: 5 bolt standard
Cooling type: oil cool only
Horsepower rating: 375+
